Parker H8-62 Hydraulic Quick Couplings

Description

Parker H8-62 Hydraulic Quick Couplings

Specifications:

• Model: H8-62
• Type: Manual Connect
• Maximum Operating Pressure: 5000 psi (345 bar)
• Maximum Operating Temperature: 250 °F (121 °C)
• Minimum Operating Temperature: -40 °C (-40 °F)
• Connection Type: Female NPTF
• Connection Thread Size: 1 – 11-1/2 inches
• Flow Rate: 50 gallons/min (189 liters/min)
• Valve Type: Poppet
• Application: General Purpose
• Body Material: Steel
• Seal Material: Nitrile
• Coupling Half: Female Coupler
• Specifications Met: ISO 7241-1, series B

Features:

• Double shut-off poppet valve design
• Interchangeable with other quick disconnects complying with ISO 7241-1 series B
• Suitable for hydraulic, fluids, gas, and steam applications
• Available in various sizes and materials
• Steam version couplers have brass construction, double interface O-rings, and stainless steel locking balls
• Seal material is Ethylene Propylene, and the 3/8″ size has a grip-ring sleeve for easy operation with gloves.
